PERKINS

Features

Marine Generator Set Technical Data

Genset Model	kW	kVA	Frequency(Hz)	Engine Model	Engine Output(kW/r/min)	Cylinders	Dimension(mm)	Weight(kg)
CCFJ10J-WTP	10	12.5	50	415GM	12.3/1500	3	1080×680×860	450
CCFJ16J-WTP	16	20	50	422GM	18.4/1500	4	1280×680×860	560
CCFJ20J-WTP	20	25	50	422TGM	25.2/1500	4	1350×680×860	600
CCFJ24J-WTP	24	30	50	4.4GM	42.7/1500	4	1560×800×1080	860
CCFJ35J-WTP	35	43.75	50	4.4GM	42.7/1500	4	1650×800×1080	900
CCFJ50J-WTP	50	62.5	50	4.4TGM	56.4/1500	4	1650×800×1080	1000
CCFJ65J-WTP	65	81.25	50	4.4TWGM	75/1500	4	1650×800×1400	1080
CCFJ80J-WTP	80	100	50	4.4TW2GM	93.6/1500	4	1650×800×1400	1120
CCFJ96J-WTP	96	120	50	E70TAG1M	109/1500	6	2040×900×1270	1860
CCFJ115J-WTP	115	143.75	50	E70TAG2M	129/1500	6	2040×900×1270	1920
CCFJ128J-WTP	128	160	50	E70TAG3M	164/1500	6	2100×900×1270	1980
CCFJ145J-WTP	145	181.25	50	E70TAG3M	164/1500	6	2140×900×1270	2040
CCFJ12J-WTP	12	15	60	415GM	14.7/1800	3	1080×680×860	450
CCFJ18J-WTP	18	22.5	60	422GM	22/1800	4	1280×680×860	560
CCFJ25J-WTP	25	31.25	60	422TGM	30.3/1800	4	1350×680×860	600
CCFJ42J-WTP	42	52.5	60	4.4GM	49.1/1800	4	1650×800×1080	900
CCFJ56J-WTP	56	70	60	4.4TGM	63.6/1800	4	1650×800×1080	1000
CCFJ70J-WTP	70	87.5	60	4.4TWGM	82.7/1800	4	1690×800×1400	1060
CCFJ95J-WTP	95	118.75	60	4.4TWG2M	106.8/1800	4	1650×800×1400	1120
CCFJ110J-WTP	110	137.5	60	E70TAG1M	129/1800	6	2040×900×1270	1860
CCFJ142J-WTP	142	177.5	60	E70TAG2M	164/1800	6	2100×900×1270	1980
CCFJ166J-WTP	166	207.5	60	E70TAG3M	191/1800	6	2140×900×1270	2040
CCFJ196J-WTP	196	245	60	E70TAG4M	218/1800	6	2200×900×1270	2160

Note: The external dimensions and weight may vary depending on the configuration.
