Features
Features
Use turbocharger technology, low engine inertia
Electronic governor controls fuel injection for quick response
Minimal recovery time under heavy load
Compared with other brands in the world, gen-set with the same bore / stroke has higher compression ratio and more power output
Use 50℃ water tank to make sure the cooling system can work normally in high temperature situation without power output reduction
50Hz Technical Data
| Series | Engine | Prime Power (kVA/kW) | Standby Power (kVA/kW) | Engine | Prime Power (kVA/kW) | Standby Power (kVA/kW) |
|---|---|---|---|---|---|---|
| RUI POWER | WP3.2D20E310 | 20/16 | 22.5/18 | WP4.1D84E310 | 85/68 | 93/74.5 |
| WP3.2D28E310 | 28/22 | 31/25 | WP4.1D105E310 | / | 118/95 | |
| WP3.2D36E310 | 37.5/30 | 41/33 | WP4.6ND120E310 | 114/91 | 136/109 | |
| WP3.2D44E310 | 41/33 | 50/40 | WP4.6ND138E310 | 112.5/90 | 156/125 | |
| WP4.1D66E310 | 67.5/54 | 75/60 | WP4.6ND148E310 | 153/122.7 | 168/134.5 | |
| WEICHAI POWER | WP7D185E310 | 191/152.7 | 210/168 | WP10D320E350 | / | 362.5/290 |
| WP7D240E310 | 247.5/198 | 272/218 | WP13D385E310 | 397/318 | 437.5/350 | |
| WP7D264E310 | 267/213.6 | 300/240 | WP13D440E310 | / | 500/400 | |
| WP10D264E350 | 272/218 | 300/240 | WP13D490E310 | / | 556/445 | |
| BAUDOUIN POWER | 6M33D633E310 | 652/522 | 718/575 | 16M33D1580E310 | 1625/1300 | 1795/1436 |
| 6M33D725E310 | / | 823/659 | 16M33D1680E310 | 1737.5/1390 | 1908/1527 | |
| 8M33D800E310 | 828/663 | 908/727 | 16M33D1800E310 | 1909/1527 | 2045/1636 | |
| 8M33D895E310 | 926/741 | 1016/813 | 16M33D1980E310 | / | 2250/1800 | |
| 8M33D975E310 | 1011/809 | 1107.5/886 | 20M33D2210E310 | / | 2511/2009 | |
| 12M33D968E310 | 1000/800 | 1100/880 | 12M55D2450E310 | / | 2783/2227 | |
| 12M33D1108E310 | 1143/915 | 1271/1007 | 12M55D2700E310 | / | 3067/2454 | |
| 12M33D1240E310 | 1283/1027 | 1408/1127 | 16M55D2750E310 | / | 3125/2500 | |
| 12M33D1320E310 | 1362/1090 | 1500/1200 | 16M55D2900E310 | / | 3295/2636 | |
| 12M33D1500E310 | / | 1703/1363 | 16M55D3300E310 | / | 3750/3000 | |
| 16M55D3600E310 | / | 4090/3272 |
60Hz Technical Data
| Series | Engine | Prime Power (kVA/kW) | Standby Power (kVA/kW) |
|---|---|---|---|
| WEICHAI POWER | WP13D460E311 | / | 500/400 |
| WP13D510E311 | / | 556/445 | |
| BAUDOUIN POWER | 6M33D740E311 | / | 823/659 |
| 8M33D1012E311 | 1011/809 | 1107.5/886 | |
| 16M33D1680E311 | 1625/1300 | 1795/1436 | |
| 16M33D1785E311 | 1737.5/1390 | 1908/1527 | |
| 16M33D1920E311 | 1909/1527 | 2045/1636 | |
| 20M33D2460E311 | / | 2511/2009 | |
| 12M55D2700E311 | / | 2783/2227 | |
| 16M55D3150E311 | / | 3125/2500 | |
| 16M55D3350E311 | / | 3295/2636 | |
| 16M55D3600E311 | / | 3750/3000 |
