Features
Features
- 2000 series use electronically controlled unit pump for fuel injection, 4000 series use common rail fuel injection system.
- Advanced electronic management system (MDEC/ADEC), ECU alarm function with excellent performance, realize fault self-diagnosis and automatic display, intelligent operation.
- Advanced two-circuit cooling water recirculating system keeps the engine in thermal equilibrium at all times, ensure the high reliability of the engine.
- Optimized fuel control system, lowest fuel consumption rate among the similar products in the world.
- The time interval of changing high quality oil reaches 1000 hours, and the optimized fuel control system can be operated 24 hours.
50Hz Technical Data
50Hz Technical Data
| Model | Rated Power(kVA/kW) | Standby Power(kVA/kW) | Engine | L/h | Number of Cylinders | Displacement(L) | Dimension Open Type(mm) | Weight Open Type(kg) | Dimension Silent Type(mm) | Weight Silent Type(kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| TPD715M5 | 650/520 | 715/572 | 12V2000G25 | 138.5 | 12V | 23.9 | 3800*1500*2080 | 4800 | 5200*2250*2500 | 8380 |
| TPD880M5 | 800/640 | 880/704 | 12V2000G65 | 165.2 | 12V | 23.9 | 3920*1500*2130 | 5150 | 5200*2250*2500 | 8600 |
| TPD1018M5 | 925/740 | 1018/814 | 16V2000G25 | 188.7 | 16V | 31.8 | 4300*1650*2350 | 6500 | 5500*2250*2540 | 9850 |
| TPD1128M5 | 1025/820 | 1128/902 | 16V2000G65 | 207.3 | 16V | 31.8 | 4400*1650*2350 | 6600 | 5500*2250*2540 | 10500 |
| TPD1250M5 | 1136/909 | 1250/1000 | 18V2000G65 | 237.6 | 18V | 35.8 | 4650*2050*2700 | 7500 | 5900*2250*2540 | 11500 |
| TPD1815M5 | 1650/1320 | 1815/1452 | 12V4000G14F | 350.2 | 12V | 57.2 | 5320*2085*2755 | 10860 | 12192*2438*2896 | 14500 |
| TPD2024M5-1 | 1840/1472 | 2024/1619 | 12V4000G63F | 355.8 | 12V | 57.2 | 5780*2400*2900 | 13450 | Please consult the factory | |
| TPD2024M5-2 | 1840/1472 | 2024/1619 | 12V4000G74F | 355.8 | 12V | 57.2 | 5780*2400*2900 | 13450 | Please consult the factory | |
| TPD2269M5-1 | 2063/1650 | 2269/1815 | 16V4000G23F | 406.1 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2269M5-2 | 2063/1650 | 2269/1815 | 16V4000G14F | 406.1 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2475M5-1 | 2250/1800 | 2475/1980 | 16V4000G63F | 441.5 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2475M5-2 | 2250/1800 | 2475/1980 | 16V4000G24F | 441.5 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2750M5-1 | 2500/2000 | 2750/2200 | 20V4000G23F | 504.7 | 20V | 95.4 | 6160*2000*2502 | 16600 | 12192*2438*2896 | 21000 |
| TPD2750M5-2 | 2500/2000 | 2750/2200 | 20V4000G14F | 504.7 | 20V | 95.4 | 6160*2000*2502 | 16600 | 12192*2438*2896 | 21000 |
| TPD3025M5-1 | 2750/2200 | 3025/2420 | 20V4000G63F | 549.5 | 20V | 95.4 | 6260*2000*2502 | 17600 | 12192*2438*2896 | 22000 |
| TPD3025M5-2 | 2750/2200 | 3025/2420 | 20V4000G24F | 549.5 | 20V | 95.4 | 6260*2000*2502 | 17600 | 12192*2438*2896 | 22000 |
| TPD3300M5-1 | 3000/2400 | 3300/2640 | 20V4000G63LF | 585 | 20V | 95.4 | 6360*2000*2502 | 18600 | 12192*2438*2896 | 23000 |
| TPD3300M5-2 | 3000/2400 | 3300/2640 | 20V4000G34F | 585 | 20V | 95.4 | 6360*2000*2502 | 18600 | 12192*2438*2896 | 23000 |
60Hz Technical Data
60Hz Technical Data
| Model | Rated Power(kVA/kW) | Standby Power(kVA/kW) | Engine | L/h | Number of Cylinders | Displacement(L) | Dimension Open Type(mm) | Weight Open Type(kg) | Dimension Silent Type(mm) | Weight Silent Type(kg) |
|---|---|---|---|---|---|---|---|---|---|---|
| TPD888M6 | 807/645 | 888/710 | 12V2000G45 | 138.5 | 12V | 23.9 | 3600*1500*2000 | 4500 | 5200*2250*2500 | 8300 |
| TPD1013M6 | 920/736 | 1013/810 | 12V2000G85 | 165.2 | 12V | 23.9 | 3920*1500*2130 | 5150 | 5200*2250*2500 | 8600 |
| TPD1144M6 | 1040/831 | 1144/915 | 16V2000G45 | 188.7 | 16V | 31.8 | 4300*1650*2350 | 6500 | 5500*2250*2540 | 9850 |
| TPD1263M6 | 1148/918 | 1263/1010 | 16V2000G85 | 207.3 | 16V | 31.8 | 4400*1650*2350 | 6600 | 5500*2250*2540 | 10500 |
| TPD1500M6 | 1353/1082 | 1500/1200 | 18V2000G65 | 237.6 | 18V | 35.8 | 4650*2050*2700 | 7500 | 5900*2250*2540 | 11500 |
| TPD1925M6-1 | 1750/1400 | 1925/1540 | 12V4000G43S | 350.2 | 12V | 57.2 | 5320*2085*2755 | 10960 | 12192*2438*2896 | 14500 |
| TPD1925M6-2 | 1750/1400 | 1925/1540 | 12V4000G14S | 350.2 | 12V | 57.2 | 5320*2085*2755 | 10960 | 12192*2438*2896 | 14500 |
| TPD2173M6-1 | 1975/1580 | 2173/1738 | 12V4000G83S | 355.8 | 12V | 57.2 | 5780*2400*2900 | 13450 | Please consult the factory | |
| TPD2173M6-2 | 1975/1580 | 2173/1738 | 12V4000G24S | 355.8 | 12V | 57.2 | 5780*2400*2900 | 13450 | Please consult the factory | |
| TPD2600M6-1 | 2363/1890 | 2600/2080 | 16V4000G43S | 406.1 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2600M6-2 | 2363/1890 | 2600/2080 | 16V4000G14S | 406.1 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2938M6-1 | 2663/2130 | 2938/2350 | 16V4000G83S | 441.5 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD2938M6-2 | 2663/2130 | 2938/2350 | 16V4000G24S | 441.5 | 16V | 76.3 | 6080*2580*3050 | 14200 | Please consult the factory | |
| TPD3135M6-1 | 2850/2280 | 3135/2508 | 20V4000G43S | 504.7 | 20V | 95.4 | 6160*2000*2502 | 16600 | 12192*2438*2896 | 21000 |
| TPD3135M6-2 | 2850/2280 | 3135/2508 | 20V4000G14S | 504.7 | 20V | 95.4 | 6160*2000*2502 | 16600 | 12192*2438*2896 | 21000 |
| TPD3425M6-1 | 3113/2490 | 3425/2740 | 20V4000G83S | 549.5 | 20V | 95.4 | 6260*2000*2502 | 17600 | 12192*2438*2896 | 22000 |
| TPD3425M6-2 | 3113/2490 | 3425/2740 | 20V4000G24S | 549.5 | 20V | 95.4 | 6260*2000*2502 | 17600 | 12192*2438*2896 | 22000 |
| TPD3762M6-1 | 3420/2736 | 3762/3010 | 20V4000G83L-S | 585 | 20V | 95.4 | 6360*2000*2502 | 18600 | 12192*2438*2896 | 23000 |
| TPD3762M6-2 | 3420/2736 | 3762/3010 | 20V4000G44S | 585 | 20V | 95.4 | 6360*2000*2502 | 18600 | 12192*2438*2896 | 23000 |
